Working up a sweat from carrying a heavy load? That is when the textile works at its best. Researchers at Chalmers University of Technology, Sweden, have developed a fabric that converts kinetic energy into electric power, in cooperation with the Swedish School of Textiles in Borås and the research institute Swerea IVF. The greater the load applied to the textile and the wetter it becomes the more electricity it generates. The results are now published in the Nature Partner journal Flexible Electronics.
The fabric of power
Chalmers researchers Anja Lund and Christian Müller have developed a woven fabric that generates electricity when it is stretched or exposed to pressure. The fabric can currently generate enough power to light an LED, send wireless signals or drive small electric units such as a pocket calculator or a digital watch.
The technology is based on the piezoelectric effect, which results in the generation of electricity from deformation of a piezoelectric material, such as when it is stretched. In the study the researchers created a textile by weaving a piezoelectric yarn together with an electrically conducting yarn, which is required to transport the generated electric current.
“The textile is flexible and soft and becomes even more efficient when moist or wet,” Lund says. “To demonstrate the results from our research, we use a piece of the textile in the shoulder strap of a bag. The heavier the weight packed in the bag and the more of the bag that consists of our fabric, the more electric power we obtain. When our bag is loaded with 3 kilos of books, we produce a continuous output of 4 microwatts. That is enough to intermittently light an LED. By making an entire bag from our textile, we could get enough energy to transmit wireless signals.”
The piezoelectric yarn
The piezoelectric yarn is made up of twenty-four fibers, each as thin as a strand of hair. When the fibers are sufficiently moist, they become enclosed in liquid and the yarn becomes more efficient, since this improves the electrical contact between the fibers. The technology is based on previous studies by the researchers in which they developed the piezoelectric fibers, to which they have now added a further dimension.
“The piezoelectric fibers consist of a piezoelectric shell around an electrically conducting core,” Lund says. “The piezoelectric yarn in combination with a commercial conducting yarn constitute an electric circuit connected in series.”
Previous work by the researchers on piezoelectric textiles has so far mainly focused on sensors and their ability to generate electric signals through pressure sensitivity. Using the energy to continuously drive electronic components is unique.
Ready for the real world
“Woven textiles from piezoelectric yarns makes the technology easily accessible and it could be useful in everyday life. It is also possible to add more materials to the weave or to use it as a layer in a multi-layer product. It requires some modification, but it is possible,” Lund says.
The researchers consider that the technology is, in principle, ready for larger-scale production. It is now mainly up to industrial product developers to find out how to make use of the technology. Despite the advanced technology underlying the material, the cost is relatively low and is comparable with the price of Gore-Tex. Through their collaboration with the Swedish School of Textiles in Borås, the researchers have been able to demonstrate that the yarn can be woven in industrial looms and is sufficiently wear-resistant to cope with the harsh conditions of mass production.
